: Length: 320
Width: 74
Year Built: 1996
Built By: Atlantic Marine Shipyard
PRICE: $7,000,000.00 USD
Vessel Description
The vessel was built as an all welded steel gaming vessel complying with provisions of USCG
Subchapter H (CFR 46, Parts 70 to 90), NVIC 8-93 and USCG regulations for intact and damaged
stability for vessels operating on inland waters. Capacity of the vessel is 2,990 persons.
A four story enclosed superstructure is constructed above the main deck to provide for 4 decks of
gaming space. The vessel is currently outfitted for 1100+ gaming spaces. Each gaming deck is
comprised of 2 zones with structural fire protection boundaries. Passenger spaces entail
approximately 43,000 square feet. Each passenger deck has 2 restrooms and a bar. The uppermost
deck also has a food preparation/counter area. Vessel outfitted with 2 elevators. A fully outfitted
pilothouse is located near the forward end of the uppermost deck. The below deck area occupies
propulsion, auxiliary machinery with associated tankage, marine storage, along with various gaming
support function spaces.
The main machinery consists of two diesel driven direct drive fixed propellers. Two thrusters are
installed, one forward and one aft, and power is provided by diesel driven engines. An emergency
generator is installed in a house on the port aft side of the uppermost exterior deck. HVAC supplied
by 3 Carrier 300 ton rotary screw chillers.
Principles and Characteristics
Builder:Atlantic Marine Shipyard
Year:1996
Naval Architect:Lay and Pitman
Official Number:1039617
Tonnage: 78331TC
1519 GRT
1058 NT
Length: 288 LWL
320’6″ LOA
Beam: 74′ (at Waterline)
Depth to Freeboard Deck: 17′
Drafts: 10’4″ Hull
76’10” Air
Stability Letter :USCG, 22-JUNE-2001
UWILD conducted April 2016
Certification: Certificate of Compliance – Indiana Gaming Commission, 2009-present
Certificate of Inspection – USCG, 1996-2009
Great Lakes Load Line – ABS, 1996-2009
Certificate of Documentation – current
Capacity: 2990 persons total, 2740 passengers and 250 crew
Tank Capacities: 19620 gallons – Fuel
16372 gallons – Potable Water
15350 gallons – Sanitary (Holding)
Propulsion: 2 – 1200 HP Detroit Engines Diesel Reduction, Fixed Blade
Engines:
| M2- Engine room | Port Main Engine | Detroit | 12V149 | 1200 HP | 3845 |
| M2- Engine room | Strb. Main Engine | Detroit | 12V149 | 1200 HP | 3839 |
| M2-AMR | Generator 1 | Detroit | 16V149 | 1360 KW | 14346 |
| M2-AMR | Generator 2 | Detroit | 16V149 | 1360 KW | 13294 |
| Emergency | |||||
| M2 – upper deck | Generator | Detroit | 6V92 | 250KW | 555 |
| M2- Engine room | Stem Thruster | Detroit | 08V92 | 530 HP | 715 |
| M2-FWD | Bow Thruster | Detroit | 08V92 | 530 HP | 714 |
Ground Tackle: 2 – 4 Ton Navy Stockless
8 shots of 1-7/8″ diameter chain each
1 Wind/ass, New England, 40 HP
1 Capstan – 10 HP
8 Winches, 60 Ton
Lifesaving Equipment:2 – Rescue Boat and Platforms, 2990 – Life Preservers (ADUL T) , 5 – Ring Buoys
Fire Fighting / Protection Equipment:
General Alarm
27 – Number of Standpipe/Hydrant stations
36- Hoses
2 – Fire Pumps
Fire Sprinklers throughout
Fire Detection throughout
Fixed C02 – Engine room
Fixed C02 – Emergency Generator
Fixed C02 – Thrusters
Clean Agent – IT Center
43 – Portable Extinguishers
| Passenger Area Square Footage | ||||
| Vessel | Deck | Section | Area | Sg.Ft. |
| Main | Forward | Slots | 4210 | |
| Main | Mid | Slots | 7545 | |
| 01 | Forward | Slots | 5260 | |
| M2 | 01 | Mid | Boarding | 7900 |
| 02 | Forward | Poker | 3996 | |
| 02 | Mid | Slots | 7560 | |
| 03 | Forward | Deli Prep | 950 | |
| 03 | Mid | Events | 3525 |
