: Length: 380
Width: 76
Year Built: 1997
Built By: Atlantic Marine, Jacksonville, FL
$8,000,000 USD
The vessel was built as an all welded steel gaming vessel complying with provisions of USCG Subchapter H (CFR 46, Parts 70 to 90), NVIC 9-93 and USCG regulations for intact and damaged stability for vessels operating on inland waters. Capacity of the vessel is 3500 persons.
A Four story enclosed superstructure is constructed above the main deck to provide for 3 decks of gaming space. The vessel is currently outfitted for 1100+ gaming spaces. Each gaming deck is comprised of 3 zones with structural fire protection boundaries. An open atrium is constructed between the main and 2nd decks. Passenger spaces entail approximately 45,000 square feet. Each passenger deck has 2 restrooms and a bar. The main deck also has an additional set of restrooms and food preparation/counter area. Vessel outfitted with 2 elevators and 4 escalators. A fully outfitted pilothouse is located near the forward end of the uppermost deck. The below deck areas occupies propulsion, auxiliary machinery, associated tank age, marine storage, and with various gaming support function spaces. Access to below deck areas is via enclosed stairways.
The main machinery consists of four electro-hydraulic Z-drives. Electrical power is provided by four diesel driven generators. An emergency generator is installed in a house on the starboard side of the uppermost deck. HVAC supplied by 4 trane 300 ton rotary screw chillers
Principles and Characteristics
Builder:Atlantic Marine Shipyard
Year:1997
Naval Architect:Guido Perla Associates
Official Number:1057517
Tonnage: 128051TC 7463 GRT 6902 NT
Length: 320′-6″ LWL
350″ LOA
Beam: 76′ (at Waterline)
77’4″ (at Rub Rail)
78′ (at Bridge Wings)
Depth to Freeboard Deck: 20′
Drafts: 11 ‘4″ Hull
88’10” Air
Stability Letter: USCG, 20-March-2006
Certification: UWILD conducted August 2017
Certificate of Compliance – Indiana Gaming Commission,2009-present
Certificate of Inspection – USCG, 1997-2009
Great Lakes Load Line – ABS, 1997-2009
Certificate of Documentation – current
Capacity: 3500 person, 3000 passengers and 500 crew
Tank Capacities: 43491 gallons – Fuel
54123 gallons – Potable Water
63678 gallons – Sanitary (Holding)
Propulsion: 4 – 1000 HP Schottel Z Drives
4 Blade, fixed pitch, variable speed, with kort nozzle
Engines:
| Location | Unit | Make | Model | Rating | Engine Hours |
| Engine room | Generator 1 | Caterpillar | 3516B | 1825 KW | 19260 |
| Engine room | Generator 2 | Caterpillar | 3516B | 1825 KW | 17613 |
| Engine room | Generator 3 | Caterpillar | 3516B | 1825 KW | 17842 |
| Engine room | Generator 4 | Caterpillar | 3516B | 1825 KW | 18308 |
| Upper deck | Emergency Generator | Caterpillar | 3408 | 411 KW | 542 |
Ground Tackle, Lifesaving Equipment, Fire Fighting / Protection Equipment:
2 – 5 Ton Navy Stockless Anchors
7 shots of 1-7/8″ diameter chain
1 Windlass, McElroy – 50 HP
4 Capstans, McElroy – 20 HP
3 Winches, 60 Ton
1 Capstan – 10 HP
2 – Rescue Boat and Platforms
3500 – Life Preservers (ADUL T)
12 – Ring Buoys
AEVADS / General Alarm
36 – Number of Standpipe/Hydrant stations
46- Hoses
3 – Fire Pumps
Fire Sprinklers throughout
Fire Detection throughout
Fixed C02 – Engine room
Fixed C02 – Emergency Generator
Clean Agent – IT Center
40 – Portable Extinguishers
| Passenger Area Square Footage | ||||
| Vessel | Deck | Section | Area | Sg. Ft. |
| Main | Forward | High Limit | 2600 | |
| Main | Mid | Games | 7280 | |
| Main | Aft | Baccarat | 2100 | |
| 2nd | Forward | Slots | 4850 | |
| M1 | 2nd | Mid | Boarding | 5720 |
| 2nd | Aft | High Limit Slots | 3350 | |
| 3rd | Forward | Video Poker | 2450 | |
| 3rd | Mid | Slots | 7350 | |
| 3rd | Aft | Slots | 5100 | |
